Testing the Adapters
Running Diagnostics on the New Adapter
The following is a sample sequence with sample screens for running the
diagnostics. The selections that you see during your test may be different.
Before running the test, disable the adapter (see “Suspend Traffic on an Adapter
Port” on page F-3).
1 Refer to “Accessing the Operational Diagnostics from the Service Processor”
on page 5-42 to obtain the DIAGNOSTIC MENU (Figure 5-22 on
page 5-43).
2 Type 1 and press Enter to access the Device List Page.
3 Select a device to test (for example, type 4 for ESCON) to test the ESCON
channel adapter in slot 4.
4 Select Run Interactive Test. The Test Options menu appears:
Screen 1 of 1
Test Options
LIC 287 - ESCON Channel Adapter, Slot 4
Operational Status Diagnostic Status Fault Status Network Connection
NOT CONFIGURED MESSAGE UNKNOWN UNKNOWN
Do not remove this device while testing.
Select one of the following test options:
* < 1. Run all tests excluding external wrap test >
* < 2. Run all tests including external wrap test >
Individual tests:
* < 3. PCI BUS >
* < 4. PROCESSOR >
* < 5. MEMORY >
* < 6. MEMORY PROT >
* < 7. TIMER >
* < 8. AIB >
* < 9. WRAP PLUG >
* <10. OPTICAL POWER >
* <11. LIGHT RECEPTION >
Select (1-11 or B=Back R=Refresh H=Help ):2
