Testing the Adapters
5 Type 2 and press Enter to run all tests including external wrap test. The
following panel appears:
Screen 1 of 1
Setup For Wrap Test
LIC 287 - ESCON Channel Adapter, Slot 4
Operational Status Diagnostic Status Fault Status Network Connection
NOT CONFIGURED TESTING UNKNOWN UNKNOWN
Do not remove this device while testing.
Install the wrap plug (PN 5605670) on the ESCON adapter located in slot 4
Confirm that the wrap plug is installed.
< 1. Start test. >
Select (1 or B=Back R=Refresh H=Help ):1
6 Attach the wrap plug. Type 1 and press Enter to start the test.
This is a long-running test. The Device Status and Control Menu is displayed
again. Note that the Diagnostic Status is TESTING. This indicates that the
tests are running and will take about 3 minutes to complete.
Screen 1 of 1
Device Status and Control Menu
LIC 287 - ESCON Channel Adapter, Slot 4
Operational Status Diagnostic Status Fault Status Network Connection
NOT CONFIGURED TESTING UNKNOWN UNKNOWN
Do not remove this device while testing.
Select from the following:
Disable Device
Enable Device
Run Default Test
Run Interactive Test
Loop Test - stop on first error
Loop Test - Log all errors
Stop Looping Test
< 1. View Test History Log >
< 2. View Hardware Error Log >
Select (1-2 or B=Back R=Refresh H=Help ):r
