Testing the Adapters
7 Type r and press Enter to refresh the display until the Diagnostic Status
changes from TESTING to MESSAGE. At this point, the following panel is
displayed:
Screen 1 of 1
Restore From Wrap Test
LIC 287 - ESCON Channel Adapter, Slot 4
Operational Status Diagnostic Status Fault Status Network Connection
NOT CONFIGURED MESSAGE UNKNOWN UNKNOWN
Do not remove this device while testing.
Remove the wrap plug on the ESCON adapter located in slot 4.
Reattach the fiber connection.
Select Back to see the results of the test.
Select ( B=Back R=Refresh H=Help ):b
8 Remove the wrap plug.
9 Reconnect the network cable to the adapter.
10 Select b to view the results of the test. In this example, the system reports
test completion with No Errors. If the test fails, you will receive a message
directing further action.
Screen 1 of 1
Test Results
LIC 287 - ESCON Channel Adapter, Slot 4
Operational Status Diagnostic Status Fault Status Network Connection
NOT CONFIGURED INACTIVE OK UNKNOWN
The Test Completed with No Errors.
Select ( B=Back ): b
11 Select b to return to the Device Status and Controls Menu.
5-52 3746-9X0: MAE Installation and Maintenance
