MAP 0300 (continued)
015
A yellow fault indicator LED on an adapter is ON. Replace the adapter. See
Chapter 4, “Multiaccess Enclosure FRU Exchange” on page 4-1.
Does this correct the problem?
Yes No
016
Contact your support center.
017
Restart the verification procedure. Go to Step 001 on page 3-6.
018
The yellow Wrong Slot LED indicator on an adapter is ON.
If adapter LIC 280 or LIC 281 is in slot 3, then slot 4 must be empty.
If adapter LIC 280 or LIC 281 is in slot 4, then slot 3 must be empty.
If adapter LIC 280 or LIC 281 is in slot 7, then slot 8 must be empty.
If adapter LIC 280 or LIC 281 is in slot 8, then slot 7 must be empty.
Relocate the adapter or adapters in slots 3, 4, 7, or 8 accordingly.
After relocating the adapters are all wrong slot LEDs OFF?
Yes No
019
Call your support center for assistance.
020
Restart the verification procedure. Go to Step 001 on page 3-6.
021
A yellow LED indicator for an I/O port is ON or BLINKING.
Is the yellow LED indicator BLINKING?
Yes No
022
I/O port LED ON - The adapter is defective. Replace it. See Chapter 4,
“Multiaccess Enclosure FRU Exchange” on page 4-1. Restart the verification
procedure. Go to Step 001 on page 3-6.
023
I/O port LED BLINKING -
There is a problem with the adapter, the cable, or the network. Run an external
wrap test on the I/O port.
You must install an external wrap block (plug) prior to the test. See “Adapter Wrap
Plugs (Service Kit - Part Number 30L6123)” on page 3-20 for the correct wrap
plug. See “Running Diagnostics on the New Adapter” on page 5-50 to run
diagnostics.
3-10 3746-9X0: MAE Installation and Maintenance
