When you are testing
one Parallel Channel Adapter that is interconnected
to an multiaccess enclosure with a single Parallel Channel Adapter
, use
the figure to determine how you want to connect your cables, and go to Step 1
on page 3-26.
Before After
Note:
W
T
Wrap Block
Terminator
T
MAE
MAE
MAE
To Host
T
MAE
MAE
MAE
To Host
T
W
Parallel
Channel
Adapter
to be
Tested
Figure 3-5. Interconnected Parallel Channel Adapters
Chapter 3. Multiaccess Enclosure Problem Determination 3-25
