Removing a line cord conduit from the 9080-M9S system node
To remove a line cord conduit, complete the steps in this procedure.
Procedure
1. Complete the following steps at the rear of the system.
a) Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is
plugged into a ground jack or connected to an unpainted metal surface. If not, do so now.
b) Disconnect the power cables that are plugged into the rear of the line cord conduit that you are
removing.
Figure 1. Removing the rear power cords
c) Loosen the retaining screw (A) and pull out the latch (B). Refer to the following îš³gure.
2
Power Systems: Removing and replacing parts in the 9080-M9S system
