Table 92. 7196 PDU+ specications (continued)
Characteristics Properties
Additional clearance 25 mm (0.98 in.) for circuit breakers
3 mm (0.12 in.) for outlets
Weight (not including power cord) 6.3 kg (13.8 lb)
Weight of power cord (approximate) 5.4 kg (11.8 lb)
Operating temperature at 0 - 914 m (0 - 3000
ft) (room ambient)
10 - 32°C (50 - 90°F)
Operating temperature at 914 - 2133 m
(3000 - 7000 ft) (room ambient)
10 - 35°C (50 - 95°F)
Operating humidity 8 - 80% (noncondensing)
Localized air temperature in PDU 60 °C (140 °F) maximum
Rated frequency (all feature codes) 50 - 60 Hz
Circuit breakers Six double-pole branch rated circuit breakers that are rated at
20 A
Power outlet Six IEC 320-C19 outlets that are rated at 16 A (VDE) or 20 A
(UL/CSA)
Site and hardware planning 101
