Table 21. Feature codes for hardware features (continued)
Feature
code Feature Description
1253 Extended drive cable group D For model 85E or 86E, 20 meter cable
to connect disk drives from a fourth
expansion model 85E or 86E to a
third expansion model 85E or 86E
1254 Extended drive cable group E For model 85E or 86E, 20 meter cable
to connect disk drives from a fifth
expansion model 85E or 86E to a
fourth expansion model 85E or 86E
1256 Standard drive enclosure pair For 800 GB flash drives
1257 Standard drive enclosure pair For 1.6 TB flash drives
1261 Drive cable group A Connects the disk drives to the
device adapters within the same base
model 984
1262 Drive cable group B Connects the disk drives to the
device adapters in the first expansion
model 84E
1263 Drive cable group C Connects the disk drives from a
second expansion model 84E to the
base model 984 and first expansion
model 84E
1266 Extended drive cable group C For model 84E, 20 meter cable to
connect disk drives from a second
expansion model 84E to the base
model 984 and first expansion model
84E
1303 Gen2 I/O enclosure pair
1320 PCIe cable group 1 Connects device and host adapters in
an I/O enclosure pair to the
processor.
1321 PCIe cable group 2 Connects device and host adapters in
I/O enclosure pairs to the processor.
1400 Top-exit bracket for Fibre Channel
cable
1410 Fibre Channel cable 40 m (131 ft), 50 micron OM3 or
higher, multimode LC
1411 Fibre Channel cable 31 m (102 ft), 50 micron OM3 or
higher, multimode LC/SC
1412 Fibre Channel cable 2 m (6.5 ft), 50 micron OM3 or
higher, multimode LC/SC Jumper
1420 Fibre Channel cable 31 m (102 ft), 9 micron OS1 or higher,
single mode LC
1421 Fibre Channel cable 31 m (102 ft), 9 micron OS1 or higher,
single mode LC/SC
1422 Fibre Channel cable 2 m (6.5 ft), 9 micron OS1 or higher,
single mode LC/SC Jumper
1600 High Performance Flash Enclosure
Gen2 pair with flash RAID controllers
For flash drives
Chapter 2. Hardware features 43
