Table 62. Feature codes for power cords
Feature code Power cord type Wire gauge
1062 Single-phase power cord, 200-240V, 60A, 3-pin
connector with IEC'309 service ready plug, for:
United States, Canada, Latin America, Japan,
and Taiwan (EMEA and other regions can
optionally order)
HBL360C6W, Pin and Sleeve Connector, IEC
60309, 2P3W
HBL360R6W, AC Receptacle, IEC 60309, 2P3W
10 mm² (7 AWG)
1063 Single-phase power cord, 200-240V, 63A, no
connector (pre-stripped wires, termination
ready for EMEA (except Japan), hard-wired, or
uses client provided customer connector/plug
as regionally allowed)
10 mm² (7 AWG)
1086 Three-phase WYE (3ØY) voltage (five-wire
3+N+PE), 380-415V~ (nominal line-to-line
(LL)), 30/32 A, IEC 60309 5-pin customer
connector IEC'309 service ready plug, for
EMEA (other regions under approved
circumstances, such as United States, Canada,
Latin America, Japan, and Taiwan can
optionally order)
HBL530C6V02, Pin and Sleeve Connector, IEC
60309, 4P5W
HBL530R6V02, AC Receptacle, IEC 60309,
4P5W
6 mm² (10 AWG)
1087 Three-phase Delta (3Ø∆) voltage (four-wire
3+PE (Protective Earth Ground)), 200-240V, 30
A, IEC 60309 4-pin customer connector with
IEC'309 service ready plug, for: United States,
Canada, Latin America, Japan, and Taiwan
(EMEA and other regions can optionally order)
HBL430C9W, Pin and Sleeve Connector, IEC
309, 3P4W
HBL430P9V04, Pin and Sleeve Connector, IEC
309, 3P4W
HBL430R9W, AC Receptacle, IEC 60309, 3P4W
6 mm² (10 AWG)
1088 Three-phase WYE (3ØY) voltage (five-wire
3+N+PE), 380-415V~ (nominal line-to-line
(LL)), 40 A, no customer connector provided
(pre-stripped wires, termination ready for
EMEA (except Japan), hard-wired, or uses
client provided customer connector/plug as
regionally allowed)
Inline Connector: not applicable
Receptacle: not applicable
6 mm² (10 AWG)
Chapter 4. Storage system physical configuration 111
