Chapter 5. Physical Specifications
In the following two tables, maximum power and heat specifications are based on the maximum capacity
of the power supply.
Table 32. Electrical Input
Description Measurement
Low range 90 V ac (minimum)
137 V ac (maximum)
100 to 127 V ac (nominal)
High range 180 V ac (minimum)
265 V ac (maximum)
200 to 240 V ac (nominal)
Sine-wave input 50 to 60 Hz is required
Input kilovolt-amperes, minimum (approximate) 0.08 kVA
Input kilovolt-amperes, maximum (approximate) 0.52 kVA
Table 33. Heat Output (Approximate)
Description Measurement
Minimum configuration 35 W (120 Btu per hour)
Theoretical maximum configuration
6
285 W (970 Btu per hour)
6
Under typical maximum configurations, the heat output will be significantly below the theoretical maximum.
Chapter 5. Physical Specifications
31
