Appendix A. Connector Pin Assignments
Table 43 (Page 2 of 3). Pin Assignments for the DIMM Connectors
Pin Signal Name I/O Pin Signal Name I/O
34 A2 O 118 A3 O
35 A4 O 119 A5 O
36 A6 O 120 A7 O
37 A8 O 121 A9 O
38 A10 O 122 A11 O
39 Not connected O 123 Not connected O
40 Vcc NA 124 Vcc NA
41 Vcc NA 125 Not connected NA
42 Not connected NA 126 Not connected NA
43 Ground NA 127 Ground NA
44 /OE2 O 128 Not connected NA
45 /S2 O 129 /S3 O
46 DQMB2 O 130 DQMB6 O
47 DQMB3 O 131 DQMB7 O
48 /WE2 O 132 Not connected NA
49 Vcc O 133 Vcc NA
50 Not connected NA 134 Not connected NA
51 Not connected NA 135 Not connected NA
52 CB2 I/O 136 CB6 I/O
53 CB3 I/O 137 CB7 I/O
54 Ground NA 138 Ground NA
55 DQ16 I/O 139 DQ48 I/O
56 DQ17 I/O 140 DQ49 I/O
57 DQ18 I/O 141 DQ50 I/O
58 DQ19 I/O 142 DQ51 I/O
59 Vcc NA 143 Vcc NA
60 DQ20 I/O 144 DQ52 I/O
61 Not connected NA 145 Not connected NA
62 Not connected NA 146 Not connected NA
63 Not connected NA 147 Not connected NA
64 Ground NA 148 Ground NA
65 DQ21 I/O 149 DQ53 I/O
66 DQ22 I/O 150 DQ54 I/O
67 DQ23 I/O 151 DQ55 I/O
68 Ground NA 152 Ground NA
69 DQ24 I/O 153 DQ56 I/O
70 DQ25 I/O 154 DQ57 I/O
71 DQ26 I/O 155 DQ58 I/O
72 DQ27 I/O 156 DQ59 I/O
73 Vcc NA 157 Vcc NA
74 DQ28 I/O 158 DQ60 I/O
75 DQ29 I/O 159 DQ61 I/O
76 DQ30 I/O 160 DQ62 I/O
Appendix A. Connector Pin Assignments 47
To Next Page
