Appendix B. System Address Maps
Table 52 (Page 2 of 2). DMA I/O Addresses
Address (Hex) Description Bits Byte Pointer
00D6 Channels 4–7, Mode register (write) 00–07
00D8 Channels 4–7, Clear byte pointer (write) NA
00DA Channels 4–7, Master clear (write)/temp (read) 00–07
00DC Channels 4–7, Clear Mask register (write) 00–03
00DE Channels 4–7, Write All Mask register bits 00–03
00DF Channels 5–7, 8- or 16-bit mode select 00–07
Appendix B. System Address Maps 57
