IBM iSeries 270 Analyze Hardware Problems (System Reference Codes

Reference Code Description/Action Perform all actions before exchanging Failing Items Failing Item
9117 SPCN - Control Panel interface is now working.
The SPCN to control panel interface is now working.
No action required. This reference code is logged for information only.
9212 Frame Address field not valid.
A Licensed Internal Code command had a frame address that is not valid.
Exchange the failing items for the failing node.
TWRCARD
9213 Invalid Address status, secondary node.
The address in the SPCN command does not match the assigned address of
the secondary node.
Exchange the failing items for the failing node.
TWRCARD
9214 Invalid Address Mode status
Invalid Address Mode occurred during Frame Command processing.
TWRCARD
AJDG301
9215 Invalid Frame Command status
Invalid Frame Command occurred during Frame Command processing.
TWRCARD
AJDG301
921B System Unit SPCN Port Fault status.
System Unit Port Fault occurred during Command processing.
TWRCARD
AJDG301
922B Address Unassigned status
A secondary node has no address assigned during Command processing.
TWRCARD
AJDG301
9231 Frame-to-Frame Communications Failure
A frame-to-frame communications failure occurred during STF processing.
TWRCARD
CBLALL
9232 Intrarack Communications Failure
An SPCN secondary node to frame communications failure occurred
during Command processing.
TWRCARD
CBLALL
9233 Intrarack Communications Failure
An SPCN frame to secondary node communications failure occurred
during Command processing.
TWRCARD
CBLALL
9234 Unsupported Packet Size status
Unsupported Packet Size occurred during STF and Secondary Node
Command processing.
TWRCARD
CTLPNL
SVCPROC
9235 SPCN Secondary Node Timeout status
An SPCN Secondary Node Timeout occurred during Command processing.
If the failing secondary node is in a 9406 Expansion Unit (FC 504x), go to
the “Analyzing Problems” section in the in the SY44-4934-00, FC 504x
Problem Analysis and Repair and Parts information.
TWRCARD
AJDG301
CBLALL
9236 Frame Timeout status
An SPCN Frame Node Timeout occurred during Network post processing.
TWRCARD
CBLALL
9238 Secondary Node Fault
An SPCN Secondary Node Fault occurred during Command processing.
TWRCARD
AJDG301
1xxx
System Reference Codes 115
