Reference Code Description/Action Perform all actions before exchanging Failing Items Failing Item
8300 I/O processor card or Licensed Internal Code error
A microprocessor exception occurred on the I/O processor.
STORIOA
IOP
AJDGP01
8301 Not valid condition in I/O Processor Licensed Internal Code
The Licensed Internal Code found a condition that should not have
occurred.
FI01101
AJDGP01
IOP
8400 I/O processor Licensed Internal Code error AJDGP01
9000 I/O processor card detected device error FI01105
STORIOA
9001 I/O processor card detected device configuration error
Perform SDIOP-PIP33.
SVCDOCS
9002 I/O processor card detected device error
Perform SDIOP-PIP16.
FI01105
STORIOA
FI01140
BACKPLN
FI01106
9008 I/O card does not support functions expected by devices
Perform SDIOP-PIP25.
SVCDOCS
9009 Call your next level of support for assistance SVCDOCS
9010 Cache data associated with attached devices cannot be found
Perform SDIOP-PIP19.
SVCDOCS
9011 Cache data belongs to devices other than those attached
Perform SDIOP-PIP19.
SVCDOCS
9012 IOP requires a cache adaptor card but cannot find it.
The cache adapter card is missing or broken.
Perform SDIOP-PIP29.
CACHE
9013 The IOP and attached cache adaptor card are not compatible.
Perform SDIOP-PIP19.
SVCDOCS
9020 to 9021 Array not functional due to present hardware configuration.
Perform SDIOP-PIP20.
SVCDOCS
9022 to 9024 Array not functional due to present hardware configuration.
Perform SDIOP-PIP22.
SVCDOCS
9025 Disk unit is not supported at its physical location.
Perform SDIOP-PIP21.
SVCDOCS
9026 to 9027 Array not functional due to present hardware configuration.
Perform SDIOP-PIP22.
SVCDOCS
9028 Incorrect hardware configuration change has been detected.
Reduce the number of arrays on IOP. Either move all devices in an array to
another IOP that supports arrays, or stop an array on this IOP.
SVCDOCS
2749, 2767, 2768, 2842, 2843, 2844, 284B, 284C, 284D, 284E, 286C, 286D, 286E, 286F, 5702
System Reference Codes 151
