Below is the information as shown in a MSD SCREEN:
1 - B4xx____RC01TP01RC02RC03RC04RC05
2 - DATA0012
3 - DATA0013
4- TP02TP03
5- TP04TP05
.
.
.
9 - DATA0019
The FRU information for FRU 1 would be FI1A and FI1B or for FRU 2 it would be
FI2A and FI2B, and so forth.
Each reference code has an associated Failing Item, given in the table below. Here
the failing item is a Symbolic FRU. When you use the reference code and
description when following the procedure described in the Symbolic FRU
documentation, you should end up with a hardware FRU, code update, or
directions to call your next level of support.
Each reference code also has an associated Priority Code. The first digit of the
reference code in the table below gives the priority.
v Mandatory priority reference codes start with either a 4, 5,or7.
v High priority reference codes start with either a 8, 9,orB.
v Low priority reference codes start with either a C, D,orF.
You should replace all mandatory failing items before the next IPL. A FRU with a
high priority has a high probability of resolving the problem. Replace high priority
failing items in order, one at a time with an IPL in between. A FRU with a low
priority has a low probability of resolving the problem. Replace low priority failing
items after replacement of mandatory and high priority items.
For more on the Failing Item column entries, see Table 2. System Processor Failing
Items Details — Models 840 & SB3, which follows the reference code table below.
Table 1. (B467) System Processor Reference Codes
Reference Code Description/Action Perform all actions before exchanging Failing Items Failing Item
4001 System Card(s) or BackPlane CCIN
4002 Control panel CTLPNL
4003 System Card(s) or BackPlane ANYPROC
4004 to 4005 System Sub-Card(s) CTLPNCD
4009 System Card(s) or BackPlane ANYMEM
400A to 400D System Card(s) or BackPlane CCIN
40A0 Service processor Licensed Internal Code AJDGP01
40A1 Licensed Internal Code error AJDG301
40A2 Service processor Licensed Internal Code AJDGP01
40A4 Call your next level of support for assistance NEXTLVL
40A6 Main storage failure NOMSUSE
40E1 Service processor Licensed Internal Code AJDGP01
B467
System Reference Codes 255
