IBM iSeries 800 Hardware Problem Analysis And Isolation

Failing item code Description/Action
FI00203 For the Models 270 and 820, FI00203 indicates that the remote bus expansion adapter card
in the bus expansion unit is the failing item.
Use the adapter card type in the bus expansion unit to determine the part.
For Models 830, 840, SB2, and SB3, FI00203 indicates that the remote SPD optical bus
receiver card in the expansion tower is the failing item.
Use the receiver card type in the expansion tower to determine the part.
FI00204 For Models 270 and 830, FI00204 indicates that the bus cable between the system unit and
the bus expansion unit is the failing item. For Models 830, 840, SB2, and SB3, FI00204
indicates that the bus cable between the migrated tower and the expansion tower is the
failing item.
FI00205 For Models 270 and 830, FI00205 indicates that the remote bus expansion adapter for the
paired bus is the failing item.
Use the adapter card type in the bus expansion unit to determine the part.
For Models 830, 840, SB2, and SB3, FI00205 indicates that the remote SPD optical bus
receiver on the paired bus is the failing item.
Use the receiver card type in the expansion tower bus to determine the part.
FI00206 For Models 270 and 830, FI00206 indicates that a type 2685 remote bus expansion adapter
is the failing item.
For Models 830, 840, SB2, and SB3, FI00206 indicates that a type 2685 remote SPD optical
bus receiver is the failing item.
Perform Bus PIP1 in the Migrated Expansion Tower Problem Analysis, Repair and Parts
manual on the V5R1 Supplemental Manuals web site .
FI00230 FI00230 indicates that the Licensed Internal Code for the failing node is the failing item and
needs to be restored.
Determine the type of node and select the Licensed Internal Code load.
v Primary node - AJSFDJ04
v Secondary node - AJSFDJ05
FI00235 FI00235 indicates that an SPCN cable that connects two frames or a frame to a node is the
failing item. This FI is applicable only if an SPCN cable is installed.
The following list shows the lengths and part numbers of the possible failing items:
v 6.0 meters — part 21F9469
v 15.0 meters — part 21F9358
v 30.0 meters — part 21F9359
v 60.0 meters — part 21F9360
v 100.0 meters (SPCN optical cable) — part 21F9415
v SPCN optical adapter — part 90H6287
v SPCN port cable (frame-to-node) — part 21F9362
v Frame-to-frame cable — part 87G6235
v SPCN optical adapter — part 90H6287
FI00236 This failing item is in a migrated tower. See the failing item table for this failing item in the
Migrated Expansion Tower Problem Analysis, Repair and Parts manual on the V5R1
Supplemental Manuals web site .
254 iSeries: iSeries Server 270, 800, 810, 820, 825, 830, 840, 870, 890, SB2, and SB3 Hardware Problem Analysis and
Isolation
