Failing item code Description/Action
FI00871 FI00871 indicates that the attached tape device is the failing item.
v 358x - External Ultrium drive. Refer to the device Maintenance Information manual to
determine the part number(s) to replace.
v 3590 Model Exx - External 1/2 cartridge tape drive; refer to the device Maintenance
Information manual to determine the part number(s) to replace.
v 4685 - VXA2 drive.
– For Models 270, 800, 810, and 820 system units, use P/N 97P3045
– For Models 825, 830, 840, 870, 890, SB2, SB3 system units, use P/N 97P3046
– For FC 5065, 5066, 5074, 5079 expansion towers, use P/N 97P3046
– For externally attached drives, refer to the device service information to determine the
part numbers(s) to replace.
v
6381 - Internal 1/4 inch cartridge drive with QIC-2GB (DC) on the door.
– For FC 5072, 5073, 5077 expansion towers use P/N 21H7658.
– For all other towers use P/N 59H2742.
v
6382 - Internal 1/4 inch cartridge drive with QIC-4GB (DC) on the door.
– For Models 270, 800, 810, and 820 system unit use P/N 04N2564.
– For Models 825, 830, 840, 870, 890, SB2, and SB3 system unit use P/N 53P2647.
– For FC 5072, 5073, 5077 expansion towers use P/N 21H7019.
– For FC 5065, 5074, 5079 expansion towers use P/N 53P2647.
– For all other towers use P/N 59H3745.
v
6383 - Internal 1/4 inch cartridge drive with MLR1-S on the front cover.
– For Models 270, 800, 810, and 820 system unit use P/N 04N2565.
– For Models 825, 830, 840, 870, 890, SB2, and SB3 system units use P/N 53P2648.
– For FC 5072, 5073, 5077 expansion towers use P/N 97H7717.
– For FC 5065, 5066, 5074, 5079 expansion towers use P/N 53P2648.
– For all other towers use P/N 59H4533.
v
6384 - Internal 1/4 inch cartridge drive with SLR60 on the front cover.
– For Models 270, 800, 810, and 820 system units use P/N 53P2385
– For Models 825, 830, 840, 870, 890, SB2, SB3 system units, use P/N 53P2386
– For FC 5065, 5066, 5074, 5079 expansion towers use P/N 53P2386
v
6386 - Internal 1/4 inch cartridge drive with MLR3 on the front cover.
– For Models 270, 800, 810, and 820 system units use P/N 04N2566.
– For Models 825, 830, 840, 870, 890, SB2, and SB3 system units use P/N 53P2649.
– For FC 5072, 5073, 5077 expansion towers use P/N 97H7528.
– For FC 5065, 5066, 5074, 5079 expansion towers use P/N 53P2649.
– For all other towers use P/N 59H4130.
Continued...
262 iSeries: iSeries Server 270, 800, 810, 820, 825, 830, 840, 870, 890, SB2, and SB3 Hardware Problem Analysis and
Isolation
