IBM iSeries 800 Hardware Problem Analysis And Isolation

v No: Exchange the power control compartment, AC module, or SPCN card (BKSPCN or
TWRCARD) in the frame from which you removed the SPCN optical adapter.
Note: See the Remove and replace procedures topic, or the FC 504x Problem Analysis and Repair
and Parts information (SY44-4934-00), or the Migrated Expansion Tower Problem Analysis, Repair
and Parts manual on the V5R1 Supplemental Manuals web site , depending on the secondary
frame you are working on.
This ends the procedure.
v Yes: Exchange the following FRUs, one at a time.
Note: See the Remove and replace procedures topic, or the FC 504x Problem Analysis and Repair
and Parts information (SY44-4934-00), or the Migrated Expansion Tower Problem Analysis, Repair
and Parts manual on the V5R1 Supplemental Manuals web site , depending on the secondary
frame you are working on.
– PCC in the failing frame (first frame with a failure indication).
– PCC, AC module, or SPCN card (BKSPCN or TWRCARD) in the preceding frame in the string.
– SPCN optical adapter A in the preceding frame in the string.
– SPCN optical adapter B in the failing frame.
– SPCN optical cables C between the preceding frame in the string and the failing frame.
(A) SPCN
Optical .----- (C) SPCN
adapter ----. | Optical cables
| |
| | .--- (B) SPCN
.---------. | | | Optical
| System | | | | adapter
| Unit | V | V
| J15 | .-. V .-.
’----.----’ | +------------+ |
| | +------------+ |
.----’----. .-------’-+ .-------’-+ .---------.
| J15 | | J16| | J15| | |
|Frame J16+-+J15 Frame| |Frame J16+-+J15 Frame|
| 1 | | 2 | | 3 | | 4 |
’---------’ ’---------’ ’---------’ ’---------’
^
|
|
’---Failing frame
This ends the procedure.
20.
Perform the following:
a. Power off the system.
b. Disconnect the SPCN frame-to-frame cable from J15 on the PCC of the first secondary frame that
cannot become powered on.
c. Connect the negative lead of a multimeter to the system frame ground.
d. Connect the positive lead of the multimeter to pin 2 of the SPCN cable.
Note: Use an insulated probe or jumper when performing the voltage readings.
e. Note the voltage reading on pin 2.
f. Move the positive lead of the multimeter to pin 3 of the SPCN cable.
48 iSeries: iSeries Server 270, 800, 810, 820, 825, 830, 840, 870, 890, SB2, and SB3 Hardware Problem Analysis and Isolation
