IBM iSeries 820 Analyze Hardware Problems (System Reference Codes

Reference Code Description/Action Perform all actions before exchanging Failing Items Failing Item
5720 Retry limit reached for sending poll frame to remote FI00700
CXCMODU
5721 Could not send frame to remote equipment; local problem FI00704
CXCDTAR
FI00701
FI00719
FI00730
5722 Wrong command value sent by OS/400 licensed program AJLAG01
CXCSTAD
A000 Too many devices active on the workstation IOP GXCBBBB
B000 WS IOP fails to report part, model and serial number
Perform WSAC-PIP1.
FI00615
C000, D000 WS IOP error not known AJLAG01
D001 Wrong or no external communications cable installed FI00631
AJLAG01
F003 WS IOA buffer utilization threshold exceeded temporarily AJLAG01
FFFF User believes there is a problem
Reference code FFFF is assigned by the ANZPRB (Analyze Problems) for
user-detected errors. Run ANZPRB again if the problem still exists or look
in the problem log (WRKPRB) for possible failing FRUs.
UXCFF00
Table 2. Workstation Adapter Console Failing Items Details
Failing Item Description Document Description
AJDG301 Vertical Licensed Internal Code Service Functions; APAR or LICTR
AJLAG01 Licensed Internal Code Service Functions; APAR or LICTR
CXCBUSY Too many communications lines in use Communications Configuration
CXCCONF Configuration or OS/400 licensed program Communications Configuration
CXCCPTO CNNPOLLTMR value in CRTLINSDLC
command
Communications Configuration
CXCCTSV CTSTMR value in CRTLINSDLC command Communications Configuration
CXCDTAR LINESPEED value in CRTLINSDLC command Communications Configuration
CXCENCD NRZI value in CRTLINSDLC command Communications Configuration
CXCINAT INACTTMR value in CRTLINSDLC command Communications Configuration
CXCMAXI MAXFRAME value in CRTLINSDLC command Communications Configuration
CXCMODU MODULUS value in CRTLINSDLC command Communications Configuration
CXCMRTY FRAMERTY value in CRTLINSDLC command Communications Configuration
CXCMSTA MAXCTL value in CRTLINSDLC command Communications Configuration
CXCNPRT NPRDRCVTMR value in CRTLINSDLC
command
Communications Configuration
CXCRPTO IDLTMR value in CRTLINSDLC command Communications Configuration
CXCSNDT SHMNODE value in CRTLINSDLC command Communications Configuration
CXCSTAD STNADR value in CRTCTL_____command Communications Configuration
CXCTEMP No failure found Communications Configuration
