IBM iSeries 820 Analyze Hardware Problems (System Reference Codes

Reference Code Description/Action Perform all actions before exchanging Failing Items Failing Item
C300, C400, C500 System Card(s) or BackPlane CCIN
C501 to C508,
C50D to C50F,
C511 to C518,
C51D to C51F,
C521 to C528,
C52D to C52F,
C531 to C538,
C53D to C53F
System Sub-Card(s) CCIN
C5FF System Sub-Card(s) ANYMEMX
C600 to C601 System Card(s) or BackPlane CCIN
F101 to F108, F140
to F141
System bus error RIOPORT
F201, F280 Bus expansion card MUMIOCD
F281 to F283 System bus error RIOPORT
F301 Bus expansion card FI00015
F302 to F305 Optical link on Bus Expansion Adapter card failed FI00017
F306 Bus expansion card FI00015
F307 to F30A Optical link on Bus Expansion Adapter card failed FI00017
F30B Bus expansion card FI00015
F30C to F30F Optical link on Bus Expansion Adapter card failed FI00017
F3FF Bus expansion card FI00015
F401 System Card(s) or BackPlane FI00017
F402 Bus expansion card FI00017
F404 to F406 Optical link on Bus Expansion Adapter card failed FI00017
F408 Bus expansion card FI00017
F409 to F40D Optical link on Bus Expansion Adapter card failed FI00017
Table 2. System Processor Failing Items Details — Models 830 & SB2
Failing Item Description Document Description
AJDG301 Slic Code Service Functions; APAR or LICTR
AJDGP01 Service Processor Code Service Functions; APAR or LICTR
ANYMEM Main Storage Card - Location Unknown Problem Analysis; Symbolic FRU Isolation
ANYMEMX Card Problem Analysis; Symbolic FRU Isolation
ANYPROC Processor Unknown Problem Analysis; Symbolic FRU Isolation
CCIN Card Problem Analysis; Symbolic FRU Isolation
CCIN System Backplane Problem Analysis; Symbolic FRU Isolation
CTLPNCD Control Panel Card Problem Analysis; Symbolic FRU Isolation
MUMIOCD MUM IO CARD TO CEC Problem Analysis; Symbolic FRU Isolation
NEXTLVL Contact your next level of support Problem Analysis; Symbolic FRU Isolation
NOMSUSE No usable main storage Problem Analysis; Symbolic FRU Isolation
RIOPORT MUM RIO IO PORT Problem Analysis; Symbolic FRU Isolation
B437
System Reference Codes 253
