IBM iSeries 820 Analyze Hardware Problems (System Reference Codes

Reference Code Description/Action Perform all actions before exchanging Failing Items Failing Item
0902 Power Supply P03 powered off for concurrent maintenance
0903 Power Supply P04 powered off for concurrent maintenance
0904 Power Supply P05 powered off for concurrent maintenance
0905 Power Supply P06 powered off for concurrent maintenance
0F0F AC Module Failure
The SPCN node cannot determine the machine type of the box in which it
is installed.
TWRCARD
BACKPLN
21F9429
0F12 Undefined box ID, EEPROM test failed
The SPCN node cannot determine the machine type of the box in which it
is installed.
TWRCARD
BACKPLN
21F9429
0F13 Undefined box ID, Code type mismatch
The SPCN node cannot determine the machine type of the box in which it
is installed.
TWRCARD
BACKPLN
21F9429
0F1F Undefined box ID, LCD test failed
The SPCN node cannot determine the machine type of the box in which it
is installed.
TWRCARD
BACKPLN
21F9429
0F2C Unknown box ID
The SPCN node cannot determine the machine type of the box in which it
is installed.
TWRCARD
BACKPLN
21F9429
0F2D Unknown box ID, Code level mismatch.
The SPCN node cannot determine the machine type of the box in which it
is installed.
TWRCARD
BACKPLN
21F9429
0F2E SPCN Network Fault
The box ID is not defined. A network communications failure occurred.
TWRCARD
BACKPLN
21F9429
102B PCC Overcurrent
The power control compartment is causing an over current condition in the
FC 5032 Removable Storage Unit power system.
The ac module and the SPCN port cable should be exchanged together.
TWRCARD
21F5680
21F5793
21F9362
1510 Detected AC loss
Before replacing any parts, verify that the AC input voltage is correct.
PWRSPLY
TWRCARD
1511 Power supply failure PWRSPLY
TWRCARD
1512 Power supply failure PWRSPLY
TWRCARD
CBLALL
1513 to 1514 Power supply failure PWRSPLY
TWRCARD
1516 No Power Supplies Present
The required power supplies are not installed.
PWRSPLY
TWRCARD
1520 Detected AC loss
Before replacing any parts, verify that the AC input voltage is correct.
PWRSPLY
TWRCARD
1xxx
System Reference Codes 27
