Locating components—tower model
To install options in your computer, you will need to remove the cover.
See “Removing the cover — tower model” on page 56. You also will need
to locate components inside your computer.
The following illustration will help you locate the various components in
your computer.
Adapter Card
Power Supply
System Board
Note: If you prefer, you can place the computer on its side to install or
remove options.
58 PC 300GL User Guide
