Moving the power supply— desktop model
To install a drive in the empty drive bay of your desktop model computer,
you will need to move the power supply to attach signal and power cables
to the rear connectors of the drive that you are installing. Use the following
procedure to provide easier access to the rear of the drive bay.
DANGER
Do not detach the power supply bracket from the power supply
or remove any of the power supply screws.
1. Unscrew the four screws securing the power supply to the rear of the
computer.
2. Remove the air duct from the power supply.
3. Slide the power supply unit toward the front of the chassis until the tab
holding the power supply to the chassis releases the power supply.
Chapter 6. Installing options 59
