Moving the power supply—tower model
To perform some operations inside the computer, you might need to move
the power supply to access parts of the system board that are difficult to see
or hard to reach. Use the following procedure to provide easier access to
the system board.
DANGER
Do not detach the power supply bracket from the power supply
or remove any of the power supply screws.
1. Remove the screw securing the power supply to the rear of the chassis.
2. Push the metal tab securing the power supply to the chassis to release
the power supply.
3. Slide the power supply unit up toward the top of the chassis.
Chapter 6. Installing options 61
