Installing internal drives — tower model
Before you begin:
Read “Safety information” on page vii and “Handling
static-sensitive devices” on page 53.
Turn off the computer and all other connected devices.
Disconnect all external cables and power cords, and then remove
the computer cover (see “Removing the cover — tower model” on
page 56).
To install an internal drive:
1. Open the swinging door in front of bays 1 and 2.
2. Remove the drive bay panel from the drive bay into which you are
installing the drive.
3. Insert a flat-bladed screwdriver into one of the slots on the static shield
and pry the static shield loose from the drive bay.
78 PC 300GL User Guide
