Table 27. Bulk power assembly (BPA) locations and failing components (continued)
Failing item name Identify LED Physical location code
DIMM U-M1-A Yes Un-Pm-C6
DIMM U-M1-B Yes Un-Pm-C7
DIMM U-M1-C Yes Un-Pm-C8
DIMM U-M1-D Yes Un-Pm-C9
DIMM U-M0-A Yes Un-Pm-C10
DIMM U-M0-B Yes Un-Pm-C11
DIMM U-M0-C Yes Un-Pm-C12
DIMM U-M0-D Yes Un-Pm-C13
DIMM V-M0-D Yes Un-Pm-C14
DIMM V-M0-C Yes Un-Pm-C15
DIMM V-M0-B Yes Un-Pm-C16
DIMM V-M0-A Yes Un-Pm-C17
DIMM T-M0-D Yes Un-Pm-C18
DIMM T-M0-C Yes Un-Pm-C19
DIMM T-M0-B Yes Un-Pm-C20
DIMM T-M0-A Yes Un-Pm-C21
DIMM T-M1-A Yes Un-Pm-C24
DIMM T-M1-B Yes Un-Pm-C25
DIMM T-M1-C Yes Un-Pm-C26
DIMM T-M1-D Yes Un-Pm-C27
DIMM S-M0-A Yes Un-Pm-C28
DIMM S-M0-B Yes Un-Pm-C29
DIMM S-M1-A Yes Un-Pm-C33
DIMM S-M1-B Yes Un-Pm-C34
DIMM S-M1-C Yes Un-Pm-C35
DIMM S-M1-D Yes Un-Pm-C36
DIMM S-M0-C Yes Un-Pm-C37
DIMM S-M0-D Yes Un-Pm-C38
MCM-S Yes Un-Pm-C32
MCM-T Yes Un-Pm-C23
MCM-U Yes Un-Pm-C22
MCM-V Yes Un-Pm-C31
Front light strip Yes Un-P10
Back light strip Yes Un-P11
Central electronics complex (CEC) cage connectors
System controller 0, 1 where m is 2 or 5
Connector J1, front light strip (J01 or J02) No Un-P1–Cm-T1
Connector J2, back light strip (J01 or J02) No Un-P1–Cm-T2
Connector J3, Ethernet connects to BHP A Yes Un-P1–Cm-T3
Connector J4, Ethernet connects to BHP B Yes Un-P1–Cm-T4
Finding parts, locations, and addresses 93
