5888 or EDR1 PCIe storage enclosure system parts
Indexed drawings show system part numbers.
System assembly
Table 193. System assembly part numbers
Index number CCIN Part number Units Description
1 46K3617 1 Top access cover assembly
2 45D4772 17 Attaching screw for top access cover assembly
(upper)
2 45D4772 10 Attaching screw for top access cover assembly
(lower)
3 41T8211 2 Power supply
4 57C3 00E6451 2 Enclosure RAID module (ERM) for FC 5888
PCIe storage enclosure
4 57C3 00E7704 2 Enclosure RAID module (ERM) for FC EDR1
PCIe storage enclosure
5 41T8234 2 Fan assembly
310 Finding parts, locations, and addresses
