Table 52. FRU locations and failing components (continued)
Failing item name Physical location code Fault and identify LED
Failing item removal and
replacement procedures
Power supply (left) Un-P1-E1 Fault only (5888 PCIe
storage enclosure)
Yes (EDR1 PCIe storage
enclosure)
For 5888 PCIe storage
enclosure, see Removing
and installing a power
supply.
For EDR1 PCIe storage
enclosure, see Removing
and installing a power
supply.
Power supply (right) Un-P1-E2 Fault only (5888 PCIe
storage enclosure)
Yes (EDR1 PCIe storage
enclosure)
Ports
SAS connector Un-P1-C1-T1
SAS connector Un-P1-C1-T2
SAS connector Un-P1-C2-T1
SAS connector Un-P1-C2-T2
PCIe x8 connector Un-P1-C1-T3 For 5888 PCIe storage
enclosure, see Connecting
your PCIe storage
enclosures..
For EDR1 PCIe storage
enclosure, see Removing
and installing a PCIe cable.
PCIe x8 connector Un-P1-C2-T3
Device physical locations
Finding parts, locations, and addresses 169
