Table 76. System assembly part numbers (continued)
Index
number
CCIN Part number Units per
assembly
Description
15 2B50 00E7160 2 Processor VRM (8205-E6C and 8205-E6D)
15 51CE 00E7162 2 Processor VRM (low wattage) (8202-E4C and
8202-E4D)
16 2C1E 00E2822 2 GX adapter
16 2BDA 00E0646 2 GX adapter
17 46K5415 1 Air divider
17 46K5417 1 Air divider on PCIe riser
18 6B1C 74Y8565 1 40 mm fan assembly on PCIe riser
19 2BE6 74Y2288 1 PCIe expansion assembly (generation 2)
20 46K5029 1 External SAS cable assembly
21 2B4C 00E0665 1 RAID and cache storage controller
Note: The RAID and cache storage controller
includes the cache battery pack.
21 74Y9340 1 Cache battery pack for RAID and cache storage
controller
21 2B4F 00E0660 1 RAID storage controller (split disk drive
function)
22 2BD6 00E1078 1 Disk drive backplane assembly (supports eight
disk drives, one SATA DVD drive, one SAS or
USB tape drive, and external SAS port)
22 2BD5 00E2520 1 Disk drive backplane assembly (supports six disk
drives, one SATA DVD drive, and one SAS or
USB tape drive)
23 1 - 6 or 1 - 8 See Disk drive and solid-state drive system parts.
24 1 DVD drive. See Managing DVD drives.
196 Finding parts, locations, and addresses
