Table 110. Final assembly (front) (continued)
Index
number
CCIN Part number Units per
assembly
Description
10 2BC2 00E5681 1 175 MB cache RAID and dual storage IOA
enablement card
Note: If feature code 5662 is installed, the
embedded SAS adapters report CCINs of 57CF.
11 1 - 6 See Disk drive and solid-state drive system parts.
Final assembly (rear)
Table 111. Final assembly part numbers (rear)
Index
number
CCIN Part number Units per
assembly
Description
12 2BC3 73Y9518 2 I/O hub 12X adapter card
12 2B94 00E2818 2 GX++ 2-port PCIe2 x8 adapter
13 2BED 00E8277 2 Power supply 1925 W
14 52F4 00E1299 1 Vital product data (VPD) card (8408-E8D or
9109-RMD only)
14 560C 00E3153 1 Vital product data (VPD) card (8248-L4T only)
15 2B57 00E0784 1 Optical - 2 x 1 GbE and 2 x 10 GbE integrated
multifunction card
230 Finding parts, locations, and addresses
