Table 133. Final assembly (front) (continued)
Index
number
CCIN Part number Units per
assembly
Description
9 2BC2 00E5681 1 175 MB cache RAID and dual storage IOA
enablement card
Note: If feature code 5662 is installed, the
embedded SAS adapters report CCINs of 57CF.
10 See Disk drive and solid-state drive system parts.
Final assembly (8412-EAD, 9117-MMD, 9179-MHC with four-processor system unit,
or 9179-MHD)
Table 134. Final assembly (front)
Index
number
CCIN Part number Units per
assembly
Description
1 74Y9391 5 Fan assembly (single fan)
2 2C4E 00E1253 1 System processor assembly FRU kit (9179-MHC
with four-processor system unit)
3 2BBD 74Y3890 1 Midplane
4 00E6658 1 Midplane light pipe
Finding parts, locations, and addresses 251
