Table 148. Final assembly (assembly 3) (continued)
Index number CCIN Part number Units Description
4 44P2994 As required Filler plate
5 77G0599 4 Screw
6 74F1823 4 Nut clip
7 44P2462 As required Filler plate
8 77G0599 2 Screw
9 74F1823 2 Nut clip
10 45D9112 8 Node locking bracket assembly (front)
11 73Y4218 As required Node assembly, unpopulated
11 95Y5058 As required Node assembly, 6 core
11 95Y5144 As required Node assembly, 8 core with 4cTurboCore
option
11 95Y5163 As required Node assembly (unpopulated)
12 15R7507 As required Node filler assembly
13 45D0534 As required EMI cover
Table 149. Final assembly (assembly 4)
Index number CCIN Part number Units Description
14 45D1994 1 UEPO assembly
15 2665528 2 Screw
16 45D5199 4 Actuator bracket assembly
Finding parts, locations, and addresses 267
