Final assembly
Table 156. Final assembly part numbers
Index
number
CCIN Part number Units per
assembly
Description
1 41T8007 2 Bulk power and control enclosure (BPCE)
2 46K3779 1 Disk enclosure
3 45D9496 1 Disk enclosure rail (right)
3 45D9466 1 Disk enclosure rail (left)
4 2 - 12 Node assembly
5 45D9467 2 Rail for node assembly (right)
6 45D9869 1 Unit emergency power off (UEPO) assembly
7 41U8423 1 - 4 Motor drive assembly (MDA)
8 15R9424 1 - 4 Water conditioning unit (WCU)
9 46K2571 1 Supply manifold
10 46K2572 1 Return manifold
Finding parts, locations, and addresses 279
