Table 15. FRU location table (continued)
Failing item name Physical location code Identify LED
Failing item
removal and
replacement
procedures
GX adapters controller slot 1 (rear view -
second slot from center)
Un-P1-C8 Yes See GX adapters.
GX Dual-Port 12X Channel Attach
adapter controller slot 2 (rear view - first
slot from center)
Un-P1-C7 Yes
GX adapters controller slot 1 port 1 (top
connector)
Un-P1-C8-T1 No
GX adapters controller slot 1 port 2
(bottom connector)
Un-P1-C8-T2 No
GX Dual-Port 12X Channel Attach
adapter controller slot 2 port 1 (top
connector)
Un-P1-C7-T1 No
GX Dual-Port 12X Channel Attach
adapter controller slot 2 port 2 (bottom
connector)
Un-P1-C7-T2 No
RAID auxiliary card Un-P1-C10 Yes See SAS RAID
enablement and
cache battery
pack.
RAID card battery Un-P1-C10-E1 No
RAID base card Un-P1-C11 Yes
Thermal management card Un-P1-C12 Yes
Memory modules
52 Finding parts, locations, and addresses
