IBM Power 710 Express 8231-E1D User Manual

Table 18. FRU location table (continued)
Failing item name Physical location code
Fault and
identify LED
Failing item
removal and
replacement
procedures
Integrated 10 Gb port Un-P2-C8-T2
Integrated 10 Gb or 1 Gb Ethernet port Un-P2-C8-T3
Integrated 10 Gb or 1 Gb Ethernet port Un-P2-C8-T4
USB top port (integrated multifunction
card)
Un-P2-C8-T5
USB bottom port (integrated
multifunction card)
Un-P2-C8-T6
Integrated serial port (integrated
multifunction card)
Un-P2-C8-T7
Serial-attached SCSI (SAS) controller A Un-P2-C9-R1
SAS controller B Un-P2-C9-R2
External SAS cable connector Un-P2-T2 Yes
Integrated Serial Advanced Technology
Attachment (SATA) controller
Un-P2-R1
Integrated serial controller Un-P2-T5 Yes
GX++ 0 connector (1) (left) Un-P1-C2-T1 Yes
GX++ 1 connector (1) (right) Un-P1-C2-T2 Yes
GX++ 0 connector (2) (left) Un-P1-C3-T1 Yes
GX++ 1 connector (2) (right) Un-P1-C3-T2 Yes
RJ-45 management port 1 Un-P1-C2-T1 Yes
RJ-45 management port 2 Un-P1-C2-T2 Yes
Processor and processor regulator
Processor voltage regulator for processor
1
Un-P3-C11 Yes See Voltage
regulator
modules.
Processor voltage regulator for processor
2
Un-P3-C18 Yes
Processor voltage regulator for processor
3
Un-P3-C14 Yes
Processor voltage regulator for processor
4
Un-P3-C15 Yes
Memory voltage regulator Un-P3-C10 Yes
Thermal power management device
(TPMD) card
Un-P3-C5 Yes See TPMD card.
Processor 1 Un-P3-C12 Yes
Processor 2 Un-P3-C17 Yes
Processor 3 Un-P3-C13 Yes
Processor 4 Un-P3-C16 Yes
Fan connector (leftmost) Un-P3-T1
Fan connector (second from left) Un-P3-T2
Fan connector (third from left) Un-P3-T3
60 Finding parts, locations, and addresses
