Table 18. FRU location table (continued)
Failing item name Physical location code
Fault and
identify LED
Failing item
removal and
replacement
procedures
Memory card 5 Un-P3-C6 Yes See Memory.
Memory card 5 - DIMM 1 Un-P3-C6-C1 Yes
Memory card 5 - DIMM 2 Un-P3-C6-C2 Yes
Memory card 5 - DIMM 3 Un-P3-C6-C3 Yes
Memory card 5 - DIMM 4 Un-P3-C6-C4 Yes
Memory card 5 - DIMM 5 Un-P3-C6-C5 Yes
Memory card 5 - DIMM 6 Un-P3-C6-C6 Yes
Memory card 5 - DIMM 7 Un-P3-C6-C7 Yes
Memory card 5 - DIMM 8 Un-P3-C6-C8 Yes
Memory card 6 Un-P3-C7 Yes See Memory.
Memory card 6 - DIMM 1 Un-P3-C7-C1 Yes
Memory card 6 - DIMM 2 Un-P3-C7-C2 Yes
Memory card 6 - DIMM 3 Un-P3-C7-C3 Yes
Memory card 6 - DIMM 4 Un-P3-C7-C4 Yes
Memory card 6 - DIMM 5 Un-P3-C7-C5 Yes
Memory card 6 - DIMM 6 Un-P3-C7-C6 Yes
Memory card 6 - DIMM 7 Un-P3-C7-C7 Yes
Memory card 6 - DIMM 8 Un-P3-C7-C8 Yes
Memory card 7 Un-P3-C8 Yes See Memory.
Memory card 7 - DIMM 1 Un-P3-C8-C1 Yes
Memory card 7 - DIMM 2 Un-P3-C8-C2 Yes
Memory card 7 - DIMM 3 Un-P3-C8-C3 Yes
Memory card 7 - DIMM 4 Un-P3-C8-C4 Yes
Memory card 7 - DIMM 5 Un-P3-C8-C5 Yes
Memory card 7 - DIMM 6 Un-P3-C8-C6 Yes
Memory card 7 - DIMM 7 Un-P3-C8-C7 Yes
Memory card 7 - DIMM 8 Un-P3-C8-C8 Yes
Memory card 8 Un-P3-C9 Yes See Memory.
Memory card 8 - DIMM 1 Un-P3-C9-C1 Yes
Memory card 8 - DIMM 2 Un-P3-C9-C2 Yes
Memory card 8 - DIMM 3 Un-P3-C9-C3 Yes
Memory card 8 - DIMM 4 Un-P3-C9-C4 Yes
Memory card 8 - DIMM 5 Un-P3-C9-C5 Yes
Memory card 8 - DIMM 6 Un-P3-C9-C6 Yes
Memory card 8 - DIMM 7 Un-P3-C9-C7 Yes
Memory card 8 - DIMM 8 Un-P3-C9-C8 Yes
Device physical locations
Finding parts, locations, and addresses 63
