Table 30. Bulk power assembly (BPA) locations and failing components (continued)
Failing item name Physical location code
Connector T23 Un-P1-C2-T23
Connector T24 Un-P1-C2-T24
Connector T25 Un-P1-C2-T25
Connector T26 Un-P1-C2-T26
Water cooling
Manifold left Un-M1
Manifold right Un-M2
Rear door heat exchanger (RDHX) Un-M3
Water conditioning unit (WCU)
WCU 1 Un-P3
MDA-W Un-P3-C1
Connector T1 Un-P3-C1-T1
Connector T2 Un-P3-C1-T2
WCU 2 Un-P4
MDA-W Un-P4-C1
Connector T1 Un-P4-C1-T1
Connector T2 Un-P4-C1-T2
WCU 3 Un-P5
MDA-W Un-P5-C1
Connector T1 Un-P5-C1-T1
Connector T2 Un-P5-C1-T2
WCU 4 Un-P6
MDA-W Un-P6-C1
Connector T1 Un-P6-C1-T1
Connector T2 Un-P6-C1-T2
Fill drain tool (FDT)
FDT - BPA 1 Un-P7
FDT control card Un-P7-C1
FDT - BPA 2 Un-P8
FDT control card Un-P8-C1
Node
Processor or hub FRU (field replaceable unit) (upper DCCA) Un-P1
DCCA 0 Un-P1-C147
Connector Un-C147-T1
Connector Un-C147-T4
HMC1 connector (FSP) Un-C147-T2
HMC2 connector (FSP) Un-C147-T3
Battery Un-C147-E1
DCCA 1 Un-P1-C148
Connector Un-C148-T1
106 Finding parts, locations, and addresses
