Table 60. IOA and device address information for running IBM i (continued)
Position Possible failing item DSA (BBBBCcbb) Unit address
Un-P2-C9-D7 Serial Advanced
Technology Attachment
(SATA) drive 1
0200-20-00 (primary)
0220-20-00 (secondary 1)
0240-20-00 (secondary 2)
0260-20-00 (secondary 3)
000000FF
5786, 5787, 7031-D24, and 7031-T24 addresses
Use the table to cross reference a disk drive physical location code to that of the SCSI cable address.
Use the address to find the location for the system, and then go to “5786, 5787, 7031-D24, and 7031-T24”
on page 130 to find additional location information.
Note: The x in the following table represents the I/O adapter number of the attached I/O card and the y
represents the SCSI bus number.
Table 61. Device cable address information
Physical location code
Unit address (SCSI cable from I/O adapter
to SCSI interface card)
Unit address (SCSI cable from SCSI
interface card to SCSI interface card)
Un-P1-D1 xy0200FF xy0A00FF
Un-P1-D2 xy0300FF xy0B00FF
Un-P1-D3 xy0400FF xy0C00FF
Un-P1-D4 xy0500FF xy0D00FF
Un-P1-D5 xy0600FF xy0E00FF
Un-P1-D6 xy0700FF xy0F00FF
Un-P1-D7 xy0200FF xy0A00FF
Un-P1-D8 xy0300FF xy0B00FF
Un-P1-D9 xy0400FF xy0C00FF
Un-P1-D10 xy0500FF xy0D00FF
Un-P1-D11 xy0600FF xy0E00FF
Un-P1-D12 xy0700FF xy0F00FF
Un-P2-D1 xy0200FF xy0A00FF
Un-P2-D2 xy0300FF xy0B00FF
Un-P2-D3 xy0400FF xy0C00FF
Un-P2-D4 xy0500FF xy0D00FF
Un-P2-D5 xy0600FF xy0E00FF
Un-P2-D6 xy0700FF xy0F00FF
Un-P2-D7 xy0200FF xy0A00FF
Un-P2-D8 xy0300FF xy0B00FF
Un-P2-D9 xy0400FF xy0C00FF
Un-P2-D10 xy0500FF xy0D00FF
Un-P2-D11 xy0600FF xy0E00FF
Un-P2-D12 xy0700FF xy0F00FF
180 Finding parts, locations, and addresses
