System assembly detail, continued
Table 71. System assembly part numbers
Index
number
CCIN Part number Units per
assembly
Description
27 537B 74Y6151 1 8 core 3.0 GHz processor module (8202-E4B)
27 537C 74Y6150 1 6 core 3.0 GHz processor module (8202-E4B)
27 537D 74Y6149 1 4 core 3.0 GHz processor module (8202-E4B)
27 539E 74Y6155 1-2 4 core 3.72 GHz processor module (8205-E6B)
27 535E 74Y6152 1-2 4 core 3.3 GHz processor module (8205-E6B)
27 539D 74Y6153 1-2 6 core 3.72 GHz processor module (8205-E6B)
27 539F 74Y6154 1-2 8 core 3.55 GHz processor module (8205-E6B)
28 44V8326 1 Heat sink
29 1 Memory card cage assembly
30 1 Attaching screw for memory card cage assembly
31 1 Processor VRM bracket
32 1 Attaching screw for processor VRM bracket
33 1 Fan lattice
34 1 Attaching screw for fan bracket
35 1 Processor VRM bracket
36 1 Attaching screw for processor VRM bracket
37 52C3 74Y1706 1 System VPD card
Finding parts, locations, and addresses 191
