Final assembly (front)
Table 121. Final assembly (front)
Index
number
CCIN Part number Units per
assembly
Description
1 46K4939 5 Fan assembly (single fan)
2 497B 74Y5976 1 System processor assembly FRU kit (9117-MMB
and 9179-MHB)
3 74Y1747 1 Mid-plane
4 46K4625 1 Mid-plane light pipe
5 2BBE 74Y5511 1 Small form factor SAS disk drive backplane with
embedded SAS adapters
Note: If feature code 5662 is not installed, the
embedded SAS adapters report CCINs of 57C7. If
feature code 5662 is installed the embedded SAS
adapters report CCINs of 57CF.
6 74Y5685 1 Op panel
7 44V4220 1 Removable media
8 42R8705 2 Cache battery pack
Finding parts, locations, and addresses 239
