Table 18. FRU location table (continued)
Failing item name Physical location code
Fault and
identify LED
Failing item
removal and
replacement
procedures
Fan connector (second from right) Un-P3-T4
Fan connector (rightmost) Un-P3-T5
Vital product data (VPD) card Un-P2-C7 See VPD card.
Service processor
Service processor USB port Un-P1-C1-T1
Time-of-day (TOD) Un-P1-C1
Time-of-day battery Un-P1-C1-E1 See Time-of-day
battery.
HMC 1 connector Un-P1-C1-T2 Identify only
HMC 2 connector Un-P1-C1-T3 Identify only
SPCN 0 connector Un-P1-C1-T4
SPCN 1 connector Un-P1-C1-T5
Ambient temperature sensor Un-D1
Adapters
PCIe adapter in slot 1 Un-P2-C1 Yes See PCI adapters.
PCIe adapter in slot 2 Un-P2-C2 Yes
PCIe adapter in slot 3 Un-P2-C3 Yes
PCIe adapter in slot 4 Un-P2-C4 Yes
PCIe adapter in slot 5 Un-P2-C5 Yes
PCIe adapter in slot 6 Un-P2-C6 Yes
1 Gb or 10 Gb integrated multifunction
card
Un-P2-C8 Yes See Integrated
multifunction
cards.
Service processor card Un-P1-C1 Yes See Service
processor card.
Expansion card - GX++ (Slot 1) Un-P1-C2 Yes See GX adapters.
Expansion card - GX++ (Slot 2) Un-P1-C3 Yes
Disk drive controller Un-P2-C9 Yes
175 MB cache RAID and dual storage
IOA enablement card
Un-P2-C9-C1 Yes
Memory modules
Finding parts, locations, and addresses 61
