Disk enclosure
Table 158. Final assembly part numbers
Index
number
CCIN Part number Units per
assembly
Description
1 46K3785 SAS expander card
1 46K3232 2 - 16 2 port disk enclosure (DE) SAS expander card
1 2A4A 46K3230 2 - 16 4 port DE SAS expander card
2 1 Disk assembly
2 41U9323 Disk enclosure chassis
3 2C80 45D9868 12 Disk enclosure fan assembly
4 74Y7329 2 Retention block (right)
4 1624793 2 Attaching screw for retention block (right)
5 2A4D 46K3779 2 Disk enclosure - Direct converter and control
assembly (DE - DCCA)
6 74Y7328 2 Retention block (left)
6 1624793 2 Attaching screw for retention block (left)
7 74Y4936 1 - 4 600 GB small form factor SAS 10k rpm, hard-disk
drive
Finding parts, locations, and addresses 281
