Table 12. FRU location table (continued)

Failing item name Physical location code Identify LED

Failing item

removal and

replacement

procedures

Disk drive backplane Un-P3 Yes See Disk drive

backplane.

Ports

System port 1 Un-P1-T1 No

System port 2 Un-P1-T2 No

HMC port 1 Un-P1-T3 No

HMC port 2 Un-P1-T4 No

USB port 1 Un-P1-T5 No

USB port 2 Un-P1-T6 No

SPCN port 1 Un-P1-T7 No

SPCN port 2 Un-P1-T8 No

Processor and processor regulator

POWER7 processor module 1 Un-P1-C11 Yes See System

processor

module.

POWER7 processor module 2 Un-P1-C10 Yes

POWER7 processor module 1 VRM Un-P1-C12 Yes See Voltage

regulator module.

POWER7 processor module 2 VRM Un-P1-C9 Yes

Adapters

PCIe x8 G2 slot 1 Un-P1-C2 Yes See PCI adapters.

PCIe x8 G2 slot 2 Un-P1-C3 Yes

PCIe x8 G2 slot 3 Un-P1-C4 Yes

PCIe x8 G2 slot 4 Un-P1-C5 Yes

PCIe x8 G2 slot 5 Un-P1-C6 Yes

PCIe x4 G2 slot 6 Un-P1-C7 Yes
