Table 18. FRU location table (continued)
Failing item name Physical location code
Fault and
identify LED
Failing item
removal and
replacement
procedures
Memory card 1 Un-P3-C1 Yes See Memory.
Memory card 1 - DIMM 1 Un-P3-C1-C1 Yes
Memory card 1 - DIMM 2 Un-P3-C1-C2 Yes
Memory card 1 - DIMM 3 Un-P3-C1-C3 Yes
Memory card 1 - DIMM 4 Un-P3-C1-C4 Yes
Memory card 1 - DIMM 5 Un-P3-C1-C5 Yes
Memory card 1 - DIMM 6 Un-P3-C1-C6 Yes
Memory card 1 - DIMM 7 Un-P3-C1-C7 Yes
Memory card 1 - DIMM 8 Un-P3-C1-C8 Yes
Memory card 2 Un-P3-C2 Yes See Memory.
Memory card 2 - DIMM 1 Un-P3-C2-C1 Yes
Memory card 2 - DIMM 2 Un-P3-C2-C2 Yes
Memory card 2 - DIMM 3 Un-P3-C2-C3 Yes
Memory card 2 - DIMM 4 Un-P3-C2-C4 Yes
Memory card 2 - DIMM 5 Un-P3-C2-C5 Yes
Memory card 2 - DIMM 6 Un-P3-C2-C6 Yes
Memory card 2 - DIMM 7 Un-P3-C2-C7 Yes
Memory card 2 - DIMM 8 Un-P3-C2-C8 Yes
Memory card 3 Un-P3-C3 Yes See Memory.
Memory card 3 - DIMM 1 Un-P3-C3-C1 Yes
Memory card 3 - DIMM 2 Un-P3-C3-C2 Yes
Memory card 3 - DIMM 3 Un-P3-C3-C3 Yes
Memory card 3 - DIMM 4 Un-P3-C3-C4 Yes
Memory card 3 - DIMM 5 Un-P3-C3-C5 Yes
Memory card 3 - DIMM 6 Un-P3-C3-C6 Yes
Memory card 3 - DIMM 7 Un-P3-C3-C7 Yes
Memory card 3 - DIMM 8 Un-P3-C3-C8 Yes
Memory card 4 Un-P3-C4 Yes See Memory.
Memory card 4 - DIMM 1 Un-P3-C4-C1 Yes
Memory card 4 - DIMM 2 Un-P3-C4-C2 Yes
Memory card 4 - DIMM 3 Un-P3-C4-C3 Yes
Memory card 4 - DIMM 4 Un-P3-C4-C4 Yes
Memory card 4 - DIMM 5 Un-P3-C4-C5 Yes
Memory card 4 - DIMM 6 Un-P3-C4-C6 Yes
Memory card 4 - DIMM 7 Un-P3-C4-C7 Yes
Memory card 4 - DIMM 8 Un-P3-C4-C8 Yes
