Table 24. FRU location table (continued)
Failing item name Physical location code Identify LED
Failing item
removal and
replacement
procedures
Small form factor SAS disk drive
backplane with embedded SAS adapters
Un-P2-C9 Yes
Ports
Integrated 10 Gb or 1 Gb Ethernet port Un-P2-C8-T1 Yes
Integrated 10 Gb or 1 Gb Ethernet port Un-P2-C8-T2 Yes
Integrated 10 Gb or 1 Gb Ethernet port Un-P2-C8-T3 Yes
Integrated 10 Gb or 1 Gb Ethernet port Un-P2-C8-T4 Yes
USB top port (integrated multifunction
card)
Un-P2-C8-T5 Yes
USB bottom port (integrated
multifunction card)
Un-P2-C8-T6 Yes
Integrated serial port (integrated
multifunction card)
Un-P2-C8-T7 Yes
External SAS cable connector Un-P2-T2 Yes
Integrated serial controller Un-P2-T5 Yes
Integrated SAS controller (A) Un-P2-C9-T1 Yes
Integrated SAS controller (B) Un-P2-C9-T2 Yes
FSP cable connector Un-P2-T1 Yes
GX++ 0 connector (1) (left) Un-P1-C2-T1 Yes
GX++ 1 connector (1) (right) Un-P1-C2-T2 Yes
GX++ 0 connector (2) (left) Un-P1-C3-T1 Yes
GX++ 1 connector (2) (right) Un-P1-C3-T2 Yes
Processor and processor regulator (9117-MMC or 9179-MHC with two-processor system unit)
Voltage Regulator Module 1 (40P VRM) Un-P3-C21 Yes
Processor Voltage Regulator Module 2
(Proc VRM)
Un-P3-C23 Yes
Voltage Regulator Module 3 (20P VRM) Un-P3-C24 Yes
Processor Voltage Regulator Module 4
(Proc VRM)
Un-P3-C26 Yes
Memory Voltage Regulator Module 5
(Mem2 VRM)
Un-P3-C5 Yes
Processor Voltage Regulator Module 6
(Proc VRM)
Un-P3-C14 Yes
Memory Voltage Regulator Module 7
(Mem2 VRM)
Un-P3-C16 Yes
TPMD card Un-P3-C15 Yes
SCM - P7-0 Un-P3-C22
SCM - P7-1 Un-P3-C25
Processor and processor regulator (8412-EAD, 9117-MMD, 9179-MHC with four-processor system unit, or
9179-MHD)
Finding parts, locations, and addresses 79
