IBM Power 770 9117-MMD User Manual

Table 3. FRU location (continued)
Failing item name Physical location code Identify LED
Failing item
removal and
replacement
procedures
Fans
Fan 1 Un-A1 Yes See Fans.
Fan 2 Un-A2 Yes
Fan 3 Un-A3 Yes
Fan 4 Un-A4 Yes
Power supplies
Power supply 1 Un-E1 Yes See Power
supply.
Power supply 1 - Cord connector Un-E1-T1 Yes
Power supply 2 Un-E2 Yes
Power supply 2 - Cord connector Un-E2-T1 Yes
Backplanes
System backplane Un-P1 Yes See System
backplane.
Time-of-day Un-P1
Time-of-day battery Un-P1-E1 See Time-of-day
battery.
Disk drive backplane Un-P2 Yes See Disk drive
backplane.
Ports
System port 1 Un-P1-T1 No
System port 2 Un-P1-T2 No
SPCN port 1 Un-P1-T3 No
SPCN port 2 Un-P1-T4 No
HMC port 1 Un-P1-T5 No
HMC port 2 Un-P1-T6 No
USB port 1 Un-P1-T7 No
USB port 2 Un-P1-T8 No
Processor and processor regulator
POWER7 processor module 1 Un-P1-C11 Yes See System
processor
module.
POWER7 processor module 2 Un-P1-C10 Yes
POWER7 processor module 1 VRM Un-P1-C12 Yes See Voltage
regulator module.
POWER7 processor module 2 VRM Un-P1-C9 Yes
Adapters
PCIe riser Un-P1-C1 No
PCIe expansion feature - PCIe x8 slot 5 Un-P1-C1-C1 No
PCIe expansion feature - PCIe x8 slot 6 Un-P1-C1-C2 No
PCIe expansion feature - PCIe x8 slot 7 Un-P1-C1-C3 No
PCIe expansion feature - PCIe x8 slot 8 Un-P1-C1-C4 No
Finding parts, locations, and addresses 11
