Table 21. FRU location table (continued)
Failing item name Physical location code Identify LED
Failing item
removal and
replacement
procedures
Memory module 10 Un-P3-C11 Yes
Memory module 11 Un-P3-C12 Yes
Memory module 12 Un-P3-C13 Yes
Memory module 13 Un-P3-C17 Yes
Memory module 14 Un-P3-C18 Yes
Memory module 15 Un-P3-C19 Yes
Memory module 16 Un-P3-C20 Yes
Device physical locations
Disk drive 1 Un-P2-C9-D1 Yes
Disk drive 2 Un-P2-C9-D2 Yes
Disk drive 3 Un-P2-C9-D3 Yes
Disk drive 4 Un-P2-C9-D4 Yes
Disk drive 5 Un-P2-C9-D5 Yes
Disk drive 6 Un-P2-C9-D6 Yes
Integrated drive electronics (IDE) drive 1 Un-P2-C9-D7 Yes
Control panel
Control panel (bottom media bay) Un -D1 See Control panel
and signal cables.
Control panel USB port Un -D1-T1
Server firmware
Server firmware Un-Y1
Related reference:
“9117-MMB and 9179-MHB system parts” on page 237
Indexed drawings show system part numbers.
8412-EAD, 9117-MMC, 9117-MMD, 9179-MHC, or 9179-MHD
The information provided in this topic defines specific sections of a location code string. Use this
information to understand the meaning of a location code.
Using location codes
For additional information about reading your location code, use the following table to link to a specific
topic.
Location code topics that might be of interest Description
“Location code overview” on page 74 Contains background information on the use of location
codes.
“Physical location codes” on page 74 Provides a definition for physical location code.
“Logical location codes” on page 74 Provides a definition for a logical location code.
“Location code format” on page 75 Provides descriptive information of the Un value in the
location code string. For example, U5886.001.
