Back assembly
Table 171. Back assembly part numbers
Index
number
CCIN Part number Units per
assembly
Description
8 45D5321 1 PCI cage multicard assembly
9 Comes with PCI cage multicard assembly and is
not a separate FRU
10 45D5229 1 EMC card assembly
11 44V5743 1 EMC filler bracket
12 44V5739 1 Power cable assembly
13 45D5008 1 SAS conduit card assembly (5802 only)
13 44V7286 1 SAS conduit card filler (5877 only)
14 45D5221 1 Midplane assembly
Table 172. Cables
CCIN Description Part number
0.6 meter SAS AT cable (SAS adapter to 5802 SAS conduit card) 44V5132
0.6 meter IB cable 45D4785
1.5 meter IB cable 45D4786
2.5 meter IB cable 45D4787
3 meter IB cable 45D5271
8 meter IB cable 45D4788
Table 173. Miscellaneous parts
CCIN Description Part number
Cable management bracket (1 piece assembly) 74Y9541
296 Finding parts, locations, and addresses
