Table 6. FRU location (continued)
Failing item name Physical location code Identify LED
Failing item
removal and
replacement
procedures
GX Dual-Port 12X Channel Attach
adapter slot 1
Un-P1-C1 Yes See GX++ 12X
channel adapters.
GX Dual-Port 12X Channel Attach
adapter slot 1 IB-2 card - Port 1
Un-P1-C1-T1 Yes
GX Dual-Port 12X Channel Attach
adapter slot 1 IB-2 card - Port 2
Un-P1-C1-T2 Yes
GX Dual-Port 12X Channel Attach
adapter slot 1 card - Port 1
Un-P1-C1-T1 Yes
GX Dual-Port 12X Channel Attach
adapter slot 1 card - Port 2
Un-P1-C1-T2 Yes
GX Dual-Port 12X Channel Attach
adapter slot 2
Note: You can either install the GX
Dual-Port 12X Channel Attach adapter
in Un-P1-C2 or the PCIe riser in
Un-P1-C1, but not both at the same time.
Un-P1-C8 Yes
GX Dual-Port 12X Channel Attach
adapter slot 2 IB-2 card - Port 1
Un-P1-C8-T1 Yes
GX Dual-Port 12X Channel Attach
adapter slot 2 IB-2 card - Port 2
Un-P1-C8-T2 Yes
GX Dual-Port 12X Channel Attach
adapter slot 2 card - Port 1
Un-P1-C8-T1 Yes
GX Dual-Port 12X Channel Attach
adapter slot 2 card - Port 2
Un-P1-C8-T2 Yes
PCIe expansion feature - Fan 1 Un-P1-C1-A1 Yes
PCIe expansion feature - Fan 2 Un-P1-C1-A2 Yes
System VPD card Un-P1-C20
Cache battery card Un-P1-C14 Yes See SAS RAID
enablement and
cache battery
pack.
Battery on cache battery card Un-P1-C14-E1 Yes
RAID storage controller or RAID and
cache storage controller
Un-P1-C19 Yes
Battery on RAID and cache storage
controller
Un-P1-C19-E1 Yes
Memory modules
Memory card 1 Un-P1-C18 Yes See Memory
modules.
Memory card 1 - DIMM 1 Un-P1-C18-C1 Yes
24 Finding parts, locations, and addresses
