Removing and replacing covers for the 8248-L4T, 8408-E8D,
or 9109-RMD
Use these instructions to remove, replace, or install covers so that you can access the hardware parts or
perform service.
Removing the front cover from the 8248-L4T, 8408-E8D, or 9109-RMD
Use this procedure to remove the cover so that you can access the hardware parts or perform service.
To remove the front cover, complete the following steps:
1. If necessary, open the front rack door.
2. Pull out the latches (A) located on both sides of the cover as shown in the following figure.
3. Pull off the cover (B) to remove it from the system unit.
Installing the front cover on the 8248-L4T, 8408-E8D, or 9109-RMD
Use this procedure to install the cover after accessing the hardware parts or performing service.
To install the front cover, complete the following steps:
1. Position the cover (A) on the front of the system unit so that the four pins on the system match the
four holes on the rear of the cover.
Figure 13. Removing the front cover
© Copyright IBM Corp. 2013 39
